Absolute Dissociation Free Energy calculations on HPCs: vDSSB tutorial for GROMACS users

Tutorial for Relative Dissociation Free Energy Calculations in GROMACS between Dissimilar Molecules Using Bidirectional Nonequilibrium Dual Topology Schemes

This is a technical tutorial for the calculation of the relative dissociation free energies (RDFE) for the SAMPL9/WP6 host-guest systems on high performing architectures using a nonequilibrium alchemical approach with the GROMACS code. The theoretical background of the methodology can be found here . As an example, we shall calculate the the RDFE between the compounds g01-g02 , two chemically distant ligands, differing in charge, shape, volume and with a small Tanimoto index.

1. Downloading paraphernalia for NE-RDFE with gromacs

Download and unzip the NE-RDFE Zenodo archive and go into the NE-RDFE main directory.
Here, each of the thirteen directories for the guests of the SAMPL9/WP6 challenge (g01, g02, ..., g13) contains three subdirectories (b, u, g) where we stored the PDB configurations of the WP6-bound guest (200), of the guest in bulk solvent (125), and of the gas-phase (200) guest. These decorrelated equilibrium conformations for the end-states can be obtained with replicates of ordinary MD simulations or using Hamiltonian Replica Exchange Method (HREM). For using HREM with GROMACS in ligand-protein or host-guest systems, see the excellent PLUMED tutorial at the PLUMED official site or go through the tutorial for absolute dissociation free energy calculations with vDSSB in GROMACS.
The directory lib contains the PrimaDORAC-generated itp files of the host and of the guest, and of OPC3 water.
The directory bin contains ancillary scripts for pre- and post- processing.
The directory data contains gromacs-computed RDFEs for the SAMPL9 batch.
The directory workdata_example contains example of work data.
The directory doc contains this tutorial.

2. Preparing the dual topology directories for RDFE calculation on an HPC

Go into the bin directory and issue the command
```
    $ source SOURCE_THIS_FILE.bash

```
This will activate all the scripts in the directory. N.B. gfortran and GROMACS must be installed.
To generate and customize a working directory where, e.g., g01 is transformed to g02, go back to the main NE-RDFE dir and issue the commands
```
    $ make_rbfe_dir.bash g01 g02 b
    $ make_rbfe_dir.bash g01 g02 u

```
This will produce the directories b-g01-g02 and u-g01-g02 with topology, ghost and coupled top/itpfiles for the dual g01-g02 topology and the starting configurations (PDB files stored in the new b-g01-PDBS and u-g01-PDBS subdirectories) with ghost and the ligand in the bound and unbound states, respectively. Note that you do not need to run an equilibrium simulation with the ghost and the fully coupled ligand to produce the starting states for the NE alchemical transitions. These initial states can be straightforwardly obtained by combining equilibrium configurations of the gas-phase ghost with equilibrium configuration of the fully coupled (bound or unbound) ligand, by making coincident the centers of mass of the two ligands. This is precisely what make_rbfe_dir.bash does using the conformations in the g??/[gub] directories.
Now go into the b-g01-g02 and issue the command
```
  $ maketpr.bash
```
If everything is OK, you should see a list of ending quotes from GROMACS. This will produce 200 subdirectories with the corresponding topol.tpr files for the bound state using the stored initial configurations in the b-g01-PDBS subdirectory.
Go back to the main NE-RDFE dir and cd into the u-g01-g02 directory and issue the command
```
  $ maketpr.bash
```
This will produce 125 subdirectories with the topol.tpr files for the unbound state using the stored initial configurations in the u-g01-PDBS subdirectory. Again you should see a list of 125 random GROMACS quotes on the standard output while the subdirectories are generated.

3. Running the NE alchemical for RDFE transition on the HPC

In the bin directory, we provide the code make_submit_slr.bash for generating a SLURM submission script for the M100 HPC system at CINECA.

From the b-g01-g02 directory issue the commands:
```
     $ make_submit_slr.bash 50
     $ sbatch submit.slr

```
This will generate and submit the submission script submit.slr requesting 50 nodes for a total of 200 GPUs.
From the u-g01-g02 directory issue the commands
```
     $ make_submit_slr.bash 31
     $ sbatch submit.slr

```
This will generate and submit the submission script submit.slr requesting 31 nodes for a total of 124 GPUs.

4. Data post-processing

Once the HPC jobs are completed, from the main directory NE-RDFE, give the command:

  $ RDFE.bash -b 1000 -u 500 g01 g02

The application script RDFE.bash (that you find in the bin directory) can be used to evaluate the work from the dhdl.xvg files produced in the previous step, as well as to compute the corresponding bidirectional estimates of the relative dissociation free energy. The above command will produce the following files in a subdirectory named Datarel .

   g01-g02_b_1000.wrk  g01-g02_u_500.wrk  g02-g01_b_1000.wrk  g02-g01_u_500.wrk

The name of these files are indicative of the pair, the state (bound o unbound) and the duration of transition specified in the b.mdp and u.mdp input files (1000 ps for the bound state and 500 ps for the unbound state). These files are all you need to produce your estimate for the RDFE between the pair g01-g02 . From the main directory, re-issue the RDFE.bash command with the option -f :

  $ RDFE.bash -b 1000 -u 500 -f g01 g02

Here, RDFE.bash computes the RDFE for the transition of g02 (initially fully coupled) to g01 (initially fully decoupled). For usage of the RDFE.bash script, just issue the command with no argumets or options. You will get on the standard output a line with something like

Dir=Datarel  Sign=1  Time_u=500  Time_b=1000  xs =3.3
g02->g01   DG_bar=   -4.71   0.41  DG_ff_G=   -5.4   0.8  DG_ff_J=   -4.7   0.4  sig_AB_u=  0.80 sig_AB_b=  2.12 ADT_AB_u=  0.30 ADT_AB_b=  0.65 DG_rr_G=   -1.8   1.2  DG_rr_J=   -4.3   0.5  sig_BA_u=  1.23 sig_BA_b=  2.96 ADT_BA_u=  3.18 ADT_BA_b=  0.23  DG_fr_G=  -5.85  0.65  DG_fr_J=  -4.45  0.28 bias_fr=  0.0  DG_rf_G=  -1.50  1.14  DG_rf_J=  -5.53  0.55 bias_rf=  0.9 DG_BAR=  -4.61 0.0 tb= 1000 tu=  500

The first entry, DG_bar= -4.71 , refers to the BAR computed RDFE in kcal/mol between g01 and g02. The negative value indicates that g02 is a stronger binder than g01 . There is no need for further correction to this RDFE, as GROMACS automatically accounts in the dhdl derivatives for the volume-dependent contribution due to the charge change in the alchemical transition (more specifically, this contribution is evaluated via the function ewald_charge_correction in the ewald module of the GROMACS code).
The output of the RDFE.bash command contains a lot of info and looks pretty awkward indeed. The meaning of the various entries is described here . To get a nicer output, save the output of the RDFE.bash command to a file (e.g. TABLE ), make a file (e.g. fields) with the entries (e.g. DG_bar DG_ff_J DG_rr_J sig_AB_b sig_BA_b sig_AB_u sig_BA_u) that you want to tabulate and issue the command.


 cat fields TABLE | make_table.awk

If you do so on the full table (TABLE_RDFE that you find in the data directory) listing 21 RDFEs involving the thirteen guests of the SAMPL9 challenge, you will get this output . There, we have chosen to print the BAR bidirectional estimate, the Jarzynski RDFE estimate for the forward process (namely g02 into g01 ), the Jarzynski estimate from the reverse process, the standard deviation forward and reverse in the bound and unbound states. These latter quantities are related to the dissipation of the processes and ultimately to the uncertainty on the estimates.

NE-RDFE in a (unix) nutshell

In the following we provide the full sequence of the commands to compute a NE-RDFE on the M100 HPC system:

  unzip NE-RDFE.zip
  cd NE-RDFE
  cd bin
# activate the scripts
  source SOURCE_THIS_FILE.bash
# g02 to g01 transmutation in the b and u states
  cd ../
  make_rbfe_dir.bash g01 g02 b
  make_rbfe_dir.bash g01 g02 u
  cd b-g01-g02
  maketpr.bash
  make_submit_slr.bash 50
  sbatch submit.slr
  cd ../u-g01-g02
  maketpr.bash
  make_submit_slr.bash 31
  sbatch submit.slr
  cd ../
# g01 to g02 transmutation in the b and u state
  make_rbfe_dir.bash g01 g02 b
  make_rbfe_dir.bash g01 g02 u
  cd b-g01-g02
  maketpr.bash
  make_submit_slr.bash 50
  sbatch submit.slr
  cd ../u-g01-g02
  maketpr.bash
  make_submit_slr.bash 31
  sbatch submit.slr
  cd ../
   ... Wait for HPC Jobs to Finish ...

# compute the RDFE
  RDFE.bash -b 1000 -u 500 -f g01 g02

Piero Procacci, Marina Macchiagodena, Marco Pagliai
Dipartimento di Chimica "Ugo Schiff", Università degli Studi di Firenze, Via della Lastruccia 3, 50019 Sesto Fiorentino, Italy
If you have any questions, please feel free to contact the authors.
